nRF52833-MS88SF31

Bluetooth 5.4 Low Energy Module

  • Bluetooth 5.4
  • Leads 42 I/O ports
  • High-performance
  • Support ANT, BLE, BLE MESH, ZIGBEE and THREAD protocols, etc

$4.30

1989 in stock

Compare
Add to wishlist

Click the button to buy related accessories:

Buy MS88EX3 Development Kit

MS88SF31-nRF52833

Model No. MS88SF31
Antenna PCB
SoCset Nordic nRF52833
Max Range 300M
Dimension(mm) 18.5×12.5×2mm
Flash 512KB
RAM 128KB
Reception Sensitivity -103dBm/-96dBm
Transmission Power -40~+8dBm
Current(TX) 0dBm-4.9mA
Current(RX) 4.6mA
GPIO 42
Certification CE, FCC, BQB, RoHS, REACH
Applications
Smart Buildings, Consumer Electronics, Smart Healthcare, Security Equipment, Automotive Devices, Smart Agriculture

MS88SF31-nRF52833

MS88SF3-nRF52833_Datesheet_K_EN
